Tusaale ahaan.: SDB3090H-3-K

Baakado & Gaarsiin

Iibinta Cutubyada

Bag/Bags

The file is encrypted. Please fill in the following information to continue accessing it

Tafaasiisha Sheyga

Ilaalinta RF Agile: Awood Hoose, Waxqabad Sare

Marka la eego spectrum RF ee dadku ku sii badanayaan oo lagu muransan yahay, ka hor joogista faragelinta iyadoo la ilaalinayo nolosha batteriga waa caqabad adag. Xalkayaga shaandhaynta horumarsan waxaa loogu talagalay in lagu bixiyo ilaalin firfircoon jiilka soo socda ee raadiyaha tabaha ah iyo hababka dareenka garashada.

La qabsiga La Qaban karo: Shaandheynta Awoodda Hoose

Nidaamyada u baahan maaraynta soo noqnoqoshada dabacsanaansan, tignoolajiyadayada Filter Power Tunable Low waxay bixisaa kontorool sax ah, wakhtiga-dhabta ah. Iyaga oo u oggolaanaya injineerada inay hagaajiyaan baasaaska duullimaadka, filtarradani waxay meesha ka saarayaan baahida bangiyada shaandhaynta beddelka ee waaweyn, si weyn u yareynaya raad PCB iyo isticmaalka awoodda labadaba.

Isku-xidhka Amniga & Degdegga ah: Shaandheynta Soo noqnoqoshada Awoodda Hoose

Marka guusha hadafku ay ku xidhan tahay ka-hortagga jammaynta iyo suurtogalnimada hoose ee isgaadhsiinta dhexda (LPI), shaandhaynta Soo noqnoqoshada Quwadda Hoose ayaa keenta. Waxaa loogu talagalay beddelka xawaaraha sare iyo daahitaanka ugu yar, shaandhadani waxay hubisaa wada-shaqaynta aan kala go 'lahayn ee borotokoollada degdegga ah ee faafinta spectrum (FHSS)-dhammaan iyada oo la ilaalinayo astaanta awoodda aadka u hooseeya.

Astaamaha Alaabta:

● Luminta Gelida Hoose
● Dhaqdhaqaaqa degdega ah
● Cabbirka is haysta
● 8-bit oo isbarbar socda Code Tuning

Qiyaasta Farsamada

Parameter Name	Unit	Characteristic
Frequency Range	MHz	30～ 90	90～ 225	225～512	512～800	800～ 1 100
3 dB Bandwidth	MHz	2～8%
Insertion Loss	dB	≤3
Selectivity	dBc	Fo±10% ≥ 15
Far-End Rejection	dBc	2 Fo≥45
P1dB	dBm	≥+30
IIP3	dBm	≥+45
VSWR		1 .5 :1 typ 1 .8 :1 max
Switching Speed	μs	30 μs max 10 μs typ
Power Supply Characteristics	mA	Vcc /+3 .3V≤120 Vbb /+100V≤2
Operating Temperature	℃	-45～ +85
Storage Temperature	℃	-55～ +105
Dimensions	mm	29×23×13 (±0 .2）

Qeexitaannada Pin:

Pin	Function
1～8	A0～A7
9	RF/IO
10	NC
11	GND
12	GND
13	GND
14	Vbb
15	Vcc
16	RF/IO

Sawirka dulucda:
