| Model | Input Voltage (VDC) | Output Voltage (VDC ±1%) | Output Current (A) | Output Power (W) | Overall Efficiency (≥ %) | Ripple (≤ mV) | Mounting Method | Package Dimensions (mm) |
| D48C3.3T75BL | 36-75 | 3.3 | 22.5 | 75 | 82 | 100 | Substrate Slotting | 1/4 Brick (57.9*36.8*12.7) |
| D48C5T100BL | 36-75 | 5 | 20 | 100 | 83 | 100 | Substrate Slotting | 1/4 Brick (57.9*36.8*12.7) |
| D48C8T100BL | 36-75 | 8 | 12.5 | 100 | 86 | 152 | Substrate Slotting | 1/4 Brick (57.9*36.8*12.7) |
| D48C12T100BL | 36-75 | 12 | 12.5 | 150 | 88 | 212 | Substrate Slotting | 1/4 Brick (57.9*36.8*12.7) |
| D48C15T100BL | 36-75 | 15 | 10 | 150 | 89 | 150 | Substrate Slotting | 1/4 Brick (57.9*36.8*12.7) |
| D48C24T100BL | 36-75 | 24 | 6.25 | 150 | 87 | 275 | Substrate Slotting | 1/4 Brick (57.9*36.8*12.7) |
| D48C28T100BL | 36-75 | 28 | 5.36 | 150 | 87 | 138 | Substrate Slotting | 1/4 Brick (57.9*36.8*12.7) |
| D48C36T100BL | 36-75 | 36 | 4.17 | 150 | 86 | 100 | Substrate Slotting | 1/4 Brick (57.9*36.8*12.7) |
| D48C48T100BL | 36-75 | 48 | 3.13 | 150 | 88 | 115 | Substrate Slotting | 1/4 Brick (57.9*36.8*12.7) |
| D48C3.3T75BL2 | 36-75 | 3.3 | 22.5 | 75 | 82 | 100 | Substrate Threading | 1/4 Brick (57.9*36.8*12.7) |
| D48C5T100BL2 | 36-75 | 5 | 20 | 100 | 83 | 100 | Substrate Threading | 1/4 Brick (57.9*36.8*12.7) |
| D48C8T100BL2 | 36-75 | 8 | 12.5 | 100 | 86 | 152 | Substrate Threading | 1/4 Brick (57.9*36.8*12.7) |
| D48C12T100BL2 | 36-75 | 12 | 12.5 | 150 | 88 | 212 | Substrate Threading | 1/4 Brick (57.9*36.8*12.7) |
| D48C15T100BL2 | 36-75 | 15 | 10 | 150 | 89 | 150 | Substrate Threading | 1/4 Brick (57.9*36.8*12.7) |
| D48C24T100BL2 | 36-75 | 24 | 6.25 | 150 | 87 | 275 | Substrate Threading | 1/4 Brick (57.9*36.8*12.7) |
| D48C28T100BL2 | 36-75 | 28 | 5.36 | 150 | 87 | 138 | Substrate Threading | 1/4 Brick (57.9*36.8*12.7) |
| D48C36T100BL2 | 36-75 | 36 | 4.17 | 150 | 86 | 100 | Substrate Threading | 1/4 Brick (57.9*36.8*12.7) |
| D48C48T100BL2 | 36-75 | 48 | 3.13 | 150 | 88 | 115 | Substrate Threading | 1/4 Brick (57.9*36.8*12.7) |
