108-678MHz Ultra-Wideband RF Filters | Shaandheynta la dami karo ee waxqabadka sare leh

Xiga Gen 108-678MHz Ultra-Wideband RF Filters: Saxnaanta ugu dambeysa ee Maareynta Spectrum Dynamic
Muuqaalka casriga ah ee maanta si xawli ah u koraya, maaraynta faragelinta guud ahaan inta jeer ee kala duwan waxay u baahan tahay dabacsanaan iyo saxnaan aan la qiyaasi karin. Shaandhooyinkeena 108-678MHz Ultra-Wideband RF Filters waxaa loo habeeyay si ay u keenaan xulashada wax qabad sare leh, luminta galinta hoose, iyo maaraynta awooda adag ee dhammaan VHF iyo UHF spectrum.

Faa'iidooyinka iyo Codsiyada filtarrada Tunable-ku-salaysan ee Chip-ku-salaysan
Faa'iidooyinka Farsamada: Waxaan nahay kuwa ugu horreeya warshadaha adduunka oo dhan si aan u gaarno horumar tignoolajiyadeed ee 1.5-700 MHz tignoolajiyada shaandhada chip-tunable, oo muujinaya faa'iidooyinka hormuudka ah ee aan loo baahnayn sahayda korantada sare, isticmaalka korantada aadka u hooseeya, cabbirka aadka u kooban, iyo culeyska khafiifka ah.
■ Faa'iidooyinka Halbeegga: Kala duwanaanshaha korantada shaqeynaya: +3.3V ilaa +12V, oo leh nidaam caadi ah isticmaalka hadda ee 6-8 mA. Faa'iidooyinka waxaa ka mid ah cabbirka is haysta, naqshadaynta miisaanka fudud, iyo isticmaalka tamarta yar.
■ Codsiyada: Isgaarsiinta moobilka, isgaarsiinta soo noqnoqda, SDR (raadiyaha ku qeexan software), qalabka tijaabada iyo cabbiraadda, qalabka caafimaadka, iyo goobaha kale ee codsiga.

Isku-dhafka Filter Tunable Horukacsan: Waxa uu leeyahay shaandhaynta dusha sare ee shaandhaynta, taas oo u oggolaanaysa firfircoonida soo noqnoqda waqtiga-dhabta ah iyo diidmada faragelinta firfircoon.

Footprint Compact: Waxay ka faa'iideysataa tignoolajiyada casriga ah ee filtarrada la hagaajin karo si ay u keento waxqabadka ugu sarreeya ee xirmo-yar oo-yar, oo dusha sare leh.

Luminta Gelida Hoose & Q-Arrinta Sare: Waxay wanaajisaa saamiga signal-ilaa- buuqa (SNR) waxayna yaraynaysaa daadinta awoodda.

Xawaaraha toosinta degdega ah: Ku fiican codsiyada soo noqnoqda ee soo noqnoqda iyo yaraynta goobta.

Waa maxay sababta aan u dooranay shaandhadayada 108-678MHz RF?
La qabsiga Spectrum Dynamic
Shaandhooyinka taagan inta badan waxay ku dhacaan deegaan RF adag. Marka lagu daro habka shaandhaynta dhaq-dhaqaaqa leh, xalkayaga ultra-wideband wuxuu u oggolaanayaa injineerada inay si firfircoon u beddelaan inta jeer ee xarunta oo ay hagaajiyaan xawaaraha xawaaraha duulista, iyaga oo hubinaya waxqabadka ugu fiicnaanta xitaa meelaha dadku ku badan yahay.

Waxtarka Meel-Cayday
Cabbirka, miisaanka, iyo awoodda (SwaP) ayaa ah qodobbada muhiimka ah ee naqshadaynta casriga ah ee RF. Adigoo isticmaalaya filtarrada la isku hagaajin karo ee chip-cufnaanta sare leh, xariiqda badeecadan waxay si toos ah u dhexgelisaa shabakadaha hagaajinta isku dhafan ee qaab monolithic ah ama qaab moduleka-chip-ka badan. Tani waxay si aad ah u yaraynaysaa hantida ma-guurtada ah ee PCB iyada oo aan waxba loo dhimayn toosnaanta ama maaraynta awooda.

Qiyaasta Farsamada

Meelaynta Koodhka Xulashada Kooxda

Sawirka dulucda:

Soo hel jiilka xiga 108-678MHz Ultra-Wideband RF filtarrada. Muujinaya Tiknooloojiyada Filter Tunable ee horumarsan iyo Chip Tunable Filters si sax ah, kantaroolka calaamada khasaaraha hoose.
